Stainless Steel Printing Mesh

Stainless steel printing mesh

When the printers select a Stainless steel printing mesh, which has highly accurate registration, precision ink deposit control and high abrasion resistance top, the printers will get a best solution to their screens. Runtech Metal Mesh offers printing mesh which is known for its excellent dimensional stability and the narrow tolerance of its overall fabric thickness, and provides uniform and accurate aperture widths.

Stainless steel mesh
The most commonly used mesh in micro-circuit manufacturing today, is uniformed wire diameter, consistent mesh thickness and evenly tension weaves. Our screen printing mesh is dimensionally stable yet elastic enough so high-extension, drum-tight screen printing screens can be stretched and printed with a minimum off-contact distance. This capability ensures the most accurate and consistent screen printing results.

Ultra thin super stainless steel mesh
Smaller wire diameter and bigger opening area are compared to the conventional stainless steel wire mesh. Runtech Metal Mesh’s screen printing mesh provides uniform and accurate aperture widths. Our screen printing screen technology and the nature of stainless steel mesh itself make these benefits possible. For example, stainless steel’s strength allows thinner wire diameters to be used.

Calendared mesh
Our calendaring process gives the screen printing mesh a more uniform and tighter overall fabric thickness tolerance. Therefore it minimizes the ink deposit variance on screen printing screens from print to print and run to run. In addition, the ink deposit will be uniform throughout any given print. Screen printers can also expect reduced squeegee wear of their screen printing screens because the calendared wire cloth has a smoother surface.

Black Screen process
Chemically processed, surface treated stainless steel mesh with black surface, random reflection of light during the exposure process is reduced. This results in better adhesion of the emulsion, as well as higher resolution patterns and very smooth aperture walls for the best possible paste flow.





Anping Runtech Metal Mesh Stainless Steel Printing Wire Mesh

Technical Specification List:

Mesh Wire Diameter Mesh Opening Opening Area Cloth Thickness Theoretical Ink Deposit-(Vth） Theoretical Max.Tension
　 　 　 　 　 　 　 In woven 　
Count/Inch inch mm mm % inch mm cm3/m2 N/cm
60 0.0045 0.112 0.315 54 0.0088 0.224 128 75
80 0.0020 0.050 0.265 71 0.0042 0.107 76 25
80 0.0037 0.095 0.224 49 0.0075 0.190 93 90
105 0.0030 0.080 0.160 44 0.0065 0.165 73 84
120 0.0026 0.067 0.140 46 0.0055 0.140 64 69
135 0.0022 0.056 0.132 49 0.0052 0.132 65 53
145 0.0022 0.056 0.118 46 0.0047 0.120 55 57
150 0.0026 0.067 0.100 36 0.0060 0.152 55 86
165 0.0020 0.050 0.106 46 0.0043 0.109 50 51
180 0.0018 0.045 0.095 46 0.0040 0.102 47 46
200 0.0016 0.040 0.085 46 0.0035 0.089 41 40
200 0.0021 0.053 0.075 34 0.0045 0.114 39 70
230 0.0011 0.030 0.080 53 0.0025 0.063 33 26
230 0.0014 0.036 0.075 46 0.0031 0.080 37 37
250 0.0014 0.036 0.063 40 0.0031 0.079 32 42
270 0.0014 0.036 0.056 37 0.0032 0.080 30 44
280 0.0010 0.025 0.067 53 0.0020 0.050 27 22
280 0.0012 0.032 0.060 43 0.0026 0.067 28 35
300 0.0012 0.030 0.056 42 0.0027 0.068 29 34
325 0.0009 0.024 0.056 49 0.0021 0.052 25 23
325 0.0011 0.030 0.050 39 0.0025 0.063 25 32
350 0.0008 0.020 0.053 53 0.0016 0.042 22 15
400 0.0008 0.020 0.045 48 0.0018 0.045 22 20
400 0.0010 0.025 0.038 36 0.0021 0.053 19 32
450 0.0010 0.025 0.032 32 0.0022 0.056 18 31
270TW 0.0016 0.040 0.053 32 0.0033 0.085 27 54
325TW 0.0014 0.036 0.042 29 0.0032 0.081 23 53
500TW 0.0010 0.025 0.025 25 0.0022 0.060 15 40
